Removing GSR50 Recycler Stacker Lock

To remove the GSR50 Recycler Stacker lock, follow these steps:

1. Loosen and remove the screw to detach the Recycler Module Cam from the lock assembly.

2. Loosen and remove the retainer nut from the Lock Mini Cam.

3.Pull out the Lock Mini Cam and Key from the Recycler Frame.
