Removing the PIN Pad (Verifone P400)

To remove the PIN Pad device, follow these steps:

1. Turn off the 7371 SCO Full Function software and hardware systems.
2. Disconnect the PIN Pad device cable.
3. Remove two (2) M3 screws to detach the Verifone P400 PIN Pad from the PIN Pad Adapter, as shown in the image below.
