Baud Rate

Baud rate is the number of bits of data transmitted per second. Set the NCR 7895 baud rate to match the baud rate setting of the auxiliary scanner. Otherwise, data may not reach the host device or may reach it but in distorted form.

Note

The NCR 7895 does not support baud rates below 9600.

Scan one of the following bar codes to set the baud rate. By default, this parameter is set to 9600.
