Crop to Pixel Addresses
Parameter # 315, SSI # F4h F0h 3Bh (Top)
Parameter # 316, SSI # F4h F0h 3Ch (Left)
Parameter # 317, SSI # F4h F0h 3Dh (Bottom)
Parameter # 318, SSI # F4h F0h 3Eh (Right)
If Image Cropping is enabled, set the pixel addresses from (0,0) to (1279 x 959) to crop to.
Columns are numbered from 0 to 1279, rows from 0 to 956. Specify values for Top, Left, Bottom, and Right, where Top and Bottom correspond to row pixel addresses, and Left and Right correspond to column pixel addresses.
For a 4 row x 8 column image in the extreme bottom-right section of the image, set the following values:
To set the pixel address, scan each of the following bar codes, and then scan four numeric bar codes from Numeric Bar Codes that correspond to the preferred value.
Enter leading zeros as required. To correct an error or change the selection, scan the Cancel bar code in Numeric Bar Codes.
To crop the top pixel address to 3, scan 0003. The default values are the following:
Top = 0, Bottom = 959, Left = 0, Right = 1279
The scanner has a cropping resolution of 4 pixels. Setting the cropping area to less than 4 pixels (after resolution adjustment, refer to Image Size (Number of Pixels) (Parameter #302, SSI #F0h 2Eh)) transfers the entire image.
