IBM Commands (Parameter #1345, SSI #F8h 04h 41h)

The IBM/TGCS protocol defines a set of commands that can be sent to the scanner. Among the command set are the following two commands:

• Reset
• Clear Scale Pole Display

This parameter allows each of these commands to be handled uniquely.

Additionally, the IBM/TGCS host may send an unknown or unsupported command. This parameter allows users to specify how these commands are to be processed.

Scan one of the bar codes that follow to match your system requirements.

Scan one of the following bar codes to match the system requirements. By default, this parameter is set to Ignore Unknown Commands, Reboot on Reset Commands, Honor Clear Scale Pole Display Commands.
