Scan Disable Mode (Parameter #1214)

This parameter determines the behavior of the NCR 7895 when it receives a Scan Disable directive from the connected host.

Full Disable—scanning bar codes is disabled.
Transmit Disable—may scan bar codes, but transmission of bar code data is disabled.
Auto Disable—disables scanning after transmission of a bar code, and remains disabled until the host sends a Scan Enable.

Note

This feature is currently supported by IBM Table Top USB, IBM Hand-held USB, and all IBM 46XX interfaces.

Scan one of the following bar codes to select the scan disable mode. By default, this parameter is set to Full Disable.
