IBM RS‑485 Specification Version (Parameter #1729)

The IBM interface specification version selected defines how code types are reported over the IBM interface.

• Original Specification—only Symbologies that were historically supported on each individual port are reported as known.
• Version 2.2—all Symbologies covered in the newer IBM specification are reported as known with their respective code types.

Scan one of the following bar codes to select the IBM RS‑485 specification version. By default, this parameter is set to Version 2.2.
