Data Matrix Inverse (Parameter #588, SSI #F1h 4Ch)

This parameter provides options for Data Matrix inverse decoder setting.

• Regular Only—decodes regular Data Matrix bar codes only.
• Inverse Only—decodes inverse Data Matrix bar codes only.
• Inverse Autodetect—decodes both regular and inverse Data Matrix bar codes.

Scan one of the following bar codes to select the Data Matrix inverse decoder setting. By default, this parameter is set to Regular Only.
