Grid Matrix Inverse (Parameter #1719, SSI #F8h 06h B7h)

This parameter provides options for Grid Matrix inverse decoder setting.

• Regular Only—decodes Grid Matrix bar codes with normal reflectance only.
• Inverse Only—decodes Grid Matrix bar codes with inverse reflectance only.
• Inverse Autodetect—decodes both regular and inverse Grid Matrix bar codes.

Scan one of the following bar codes to select the Grid Matrix inverse decoder setting. By default, this parameter is set to Inverse Autodetect.
