Grid Matrix Mirrored (Parameter #1736, SSI #F8h 06h C8h)

This parameter provides options for mirror image Grid Matrix setting.

• Non-Mirrored Only—decodes non-mirrored Grid Matrix bar codes only.
• Mirrored Only—decodes mirrored Grid Matrix bar codes only.
• Autodetect—decodes both mirrored and non-mirrored Grid Matrix bar codes.

Scan one of the following bar codes to select the mirror image Grid Matrix setting. By default, this parameter is set to Autodetect.
