GS1 DataBar Security Level (Parameter #1706, SSI#F8h 06h AAh)

The scanner offers four levels of decode security for GS1 DataBar (GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded) bar codes.

• Security Level 0—allows the scanner to operate in its most aggressive state, while providing sufficient security decoding most in‑spec bar codes.
• Security Level 1—eliminates most mis‑decodes while maintaining reasonable aggressiveness.
• Security Level 2—select this option with greater bar code security requirements if Security Level 1 fails to eliminate mis‑decodes.
• Security Level 3—select this option to apply the highest safety requirements if mis‑decodes still occur at Security Level 2.

Scan one of the following bar codes to set the GS1 DataBar security level. By default, this parameter is set to Level 1.
