Convert Interleaved 2 of 5 to EAN-13 (Parameter #82, SSI #52h)

This parameter converts 14-character Interleaved 2 of 5 codes to EAN-13, and transmit to the host as EAN‑13.

Note

For this parameter to function, the Interleaved 2 of 5 code must be enabled, and the code must have a leading zero and a valid EAN‑13 check digit.

Scan one of the following bar codes to enable or disable converting Interleaved 2 of 5 to EAN‑13. By default, this parameter is set to Disable.
