Simulated Caps Lock

Scan Enable Simulated Caps Lock to invert upper and lower case characters on the bar code as if the Caps Lock state is enabled on the keyboard. This inversion occurs regardless of the Caps Lock state of the keyboard. By default, this parameter is set to Disable.

Note

Take note of the following:

  • Simulated Caps Lock applies to ASCII characters only.
  • Do not enable this parameter if USB Caps Lock Override is enabled.
