Prefix/Suffix Values
Key Category Parameter # P = 99, S1 = 98, S2 = 100
SSI # P = 63h, S1 = 62h, S2 = 64h
Decimal Value Parameter # P = 105, S1 = 104, S2 = 106
SSI # P = 69h, S1 = 68h, S2 = 6Ah
A prefix, one or two suffixes, or both a prefix and a suffix to scan data for use in data editing. When using host commands to set the prefix or suffix, set the key category parameter to 1, and then set the 3‑digit decimal value.
To use Prefix/Suffix Values, first set the Scan Data Transmission Format. For more information, refer to Scan Data Transmission Format (Parameter #235, SSI #EBh).
To set a value for a prefix or suffix, scan of the following bar codes, and then scan the four numeric bar codes from Numeric Bar Codes that correspond to that value. For the 4‑digit codes, refer to Character Sets. The default prefix and suffix value is 7013 <CR><LF> (Enter key).
To correct an error or change the selection, scan the Cancel bar code in Numeric Bar Codes.
