RS-232 Auxiliary Port Scale Protocol (Parameter #1247, SSI #F8h 04h DFh)
Note
Take note of the following:
- The Dual Cable Scale option must be used to assign a scale device to either the Aux 1 or Aux 2 port through the RS‑232 Device Port Configuration setting. For more information, refer to RS-232 Device Port Configuration (Parameter #1246, SSI #F8h 04h DEh).
- For details on configuring the RS‑232 ports, refer to Auxiliary Scanner Bar Codes.
The following are the available options:
- *0/0x00—SASI
- 1/0x01—DIGI
- 2/0x02—ICL OMRON (Requesting zero weight is permitted)
- 3/0x03—ICL Old OMRON (Requesting zero weight is not permitted)
- 4/0x04—ICL Portugal (Identical to ICL / Old OMRON)
Scan one of the following bar codes to set the scale protocol. By default, this parameter is set to SASI.
