Timeout Between Decodes, Same Symbol (Parameter #137, SSI #89h)
Use this option in presentation mode to prevent the scanner from continuously decoding the same bar code when it is left in the scanner’s field of view (FOV). The bar code must be out of the FOV for the timeout period before the scanner reads the same consecutive symbol. It is programmable from 0.0 to 9.9 seconds, with increments of 0.1 second. The default interval is 0.5 seconds.
To select the timeout between decodes for the same symbol, scan the bar code below, and then scan two numeric bar codes from Numeric Bar Codes that correspond to the preferred interval.
Enter a leading zero for single digit numbers.
To set an interval of 0.5 seconds, scan the bar code below, and then scan the 0 and 5 bar codes. To correct an error or change the selection, scan the Cancel bar code in Numeric Bar Codes.
