USB Serial Number Format (Parameter #1832, SSI #F8h 07h 28h)
This parameter determines the format of the iSerial Number USB Descriptor during USB enumeration.
The following table provides an example for each format.
| Value | iSerial Number return |
|---|---|
| 0 (Serial Number) | 17204010505799 |
| 1 (GUID, Firmware, Interface) | S/N:E658CFB6A2654A0EB5E1D1E31EBD00CD Rev:PAADGS00-001-R082 |
| 2 (GUID, Interface) | S/N:E658CFB6A2654A0EB5E1D1E31EBD00CD:2 |
| 3 (Serial Number, Interface) | 17204010505799:2 |
Scan one of the following bar codes to select the serial number format. By default, this parameter is set to Serial Number.
