Installing GSR50 Notebox (Cashbox) Lock

To install the GSR50 Notebox (Cashbox) Lock and Security Door, follow these steps:

1.Remove the existing GSR50 Notebox (Cashbox) Lock, if necessary. For more information, refer to Removing GSR50 Notebox (Cashbox) Lock.

2.Insert the Lock Mini Cam into the lock hole of the Notebox (Cashbox) using a key. Make sure that the key can rotate to 1/4 turn counter clockwise as shown in the image below.

3. Secure the Lock Mini Cam using a retainer nut and torque the nut to 4Nm or 35 in/lbs.

4.Attach the Notebox (Cashbox) Cam to the Lock Mini Cam using a screw. Torque the screw to 4Nm or 35 in/lbs. Note the orientation of the cam in relation to the key position as shown in the image below.

5.Close the Notebox cover.
