Installing GSR50 Recycler Stacker Lock

To install the GSR50 Recycler Stacker lock, follow these steps:

1.Remove the existing GSR50 Recycler Stacker Lock, if necessary. For more information, refer to Removing GSR50 Recycler Stacker Lock.

2.Insert the Lock Mini Cam to the Recycler frame using a key in a horizontal position as shown in the image below. Ensure that the key can rotate to 1/4 turn counter clockwise as shown in the image below.

3. Secure the Lock Mini Cam using a retainer nut and torque the nut to 4Nm or 35in/lbs.

4. Attach the Recycler Module Cam in a vertical position to the Lock Mini Cam using a screw and torque the screw to 4Nm or 35 in/lbs. Note the orientation of the cam in relation to the key position as shown in the image below.
