Composite Inverse (Parameter #1113, SSI #F8h 04h 59h)

This parameter sets Composite for either regular decode or inverse decode.

  • Regular Only—the digital scanner decodes regular Composite bar codes only (default).
  • Inverse Only—the digital scanner decodes inverse Composite bar codes only. This mode only supports Inverse Composite that has DataBar combined with CCAB. No other 1D/2D combinations. For this parameter to work as expected, enable the following parameters:
  • Composite CC-A/B (Parameter #342, SSI #F0h 56h) and the corresponding 1D Inverse or 1D Inverse Autodetect. For 1D Inverse settings, refer to Inverse 1D (Parameter #586, SSI #F1h 4Ah)
  • GS1 DataBar
Note

Take note of the following:

  • To decode regular Composite, Inverse Composite must be set to Regular Only and Inverse 1D must be set to Regular Only or Autodetect.
  • To decode inverse Composite, Inverse Composite must be set to Inverse Only and Inverse 1D must be set to Inverse Only or Autodetect.

Scan one of the following bar codes to set the Composite Inverse option. By default, this parameter is set to Regular Only.
