Inverse 1D (Parameter #586, SSI #F1h 4Ah)
This parameter provides the following options for 1D inverse decoder setting:
- Regular Only—decodes regular 1D bar codes only.
- Inverse Only—decodes inverse 1D bar codes only.
- Inverse Autodetect—decodes both regular and inverse 1D bar codes.
Note
The Inverse 1D setting may impact Composite or Inverse Composite decoding. For more information, refer to Composite Inverse (Parameter #1113, SSI #F8h 04h 59h).
Scan one of the following bar codes to set the 1D inverse decoder setting. By default, this parameter is set to Regular.
